Specification:
Characteristics |
Description |
Battery |
Polymer lithium battery,Capacity 3.7V/2900mAH; |
Working current |
Average current <60mA 3.7V; |
Sleep current |
<2mA 3.7V |
Recharge |
Micro-USB port charge, support quick charge |
GPS |
Support GPS, AGPS and LBS |
Communication |
NT35U(EG915U-EU): Cat1:B1/B3/B5/B7/B8/B20/B28 GSM:850/900/1800/1900MHz |
WIFI |
Built in WIFI chip,Support WIFI function |
Antenna type |
Built in GSM ,GPS and Wifi antenna, |
SOS |
Support SOS function for emergency alarm |
Temperature sensor |
Built in temperature sensor, to detect environmental temperature |
LED Indicator |
GSM, GPS, battery |
Remote upgrade(FOTA) |
Support remote configuration and firmware upgrade |
Wake up |
Built G-sensor, to detect the device is in static or motion status |
Multiple IP |
Support multiple IPs connecting at same time |
Working time |
Working:30 seconds Standby :10 minutes |
Q1.Can you help for design?
A:Yes,we have our own software and hardware engineer,you can give your idea to us,we can assist the design work.Provide sample for your reference.
